MIL-DTL-5675C
SOCIETY OF AUTOMOTIVE ENGINEERS (SAE)
SAE-AMS-6448
Steel Bars, Forgings, And Tubing 0.95cr - 0.22v (0.48 - 0.53c) (SAE
6150)
SAE-AMS-2700
Passivation of Corrosion Resistant Steels
SAE-AMS-QQ-P-416 Plating: Cadmium (Electrodeposited)
SAE-AMS-S-6758
Steel, Chrome-Molybdenum (4130) Bars And Reforging Stock (Aircraft
Quality)
(Copies of these documents are available online from https://www.sae.org or from the Society of
Automotive Engineers, 400 Commonwealth Drive, Warrandale, PA 15096-001.)
2.4 Order of precedence. In the event of a conflict between the text of this document and
the references cited herein, the text of this document takes precedence. Nothing in this
document, however, supersedes applicable laws and regulations unless a specific exemption has
been obtained.
3. REQUIREMENTS
3.1 First article. When specified (see 6.2), a sample shall be subjected to first article inspection in
accordance with 4.2.
3.2 Quality.
3.2.1 Statistical process control (SPC). The contractor shall implement and use statistical process
control (SPC) techniques, when possible, in the manufacturing of parts covered by this specification. The
SPC program shall be developed and maintained in accordance with EIA-557. Where SPC cannot be
utilized because of non-continuous production, a lot sampling plan for inspection with C = 0 (accept on
zero defects) may be utilized. The SPC and C = 0 programs shall be documented and maintained as part
of the overall reliability assurance program as specified in EIA-557 or equivalent. Evidence of such
compliance shall be verified by the qualifying activity as a prerequisite for qualification, effective 24
months after the date of this document. Dimensioning and tolerancing shall be in accordance with ASME
Y-14.5M.
3.3 Materials. Shackles shall be forged from materials specified herein. (see table I).
TABLE I. Materials.
Grade Classification
Materials
Required document
Grade A shackles
Steel Cadmium or Zinc plated
SAE-AMS-6448, SAE-AMS-S-
6758, SAE-AMS-QQ-P-416,
ASTM-B633
Grade B shackles
Steel Corrosion resistant
SAE-AMS-7720
Grade C shackles
Nickel - Copper - Aluminum alloy
QQ-N-286
3.3.1 Recycled, recovered, or environmentally preferable materials. Recycled, recovered, or
environmentally preferable materials should be used to the maximum extent possible provided that the
material meets or exceeds the operational and maintenance requirements, and promotes economically
advantageous life cycle cost.
3
