FF-T-276C
Diameter, minimum
Weight
10 thimbles
Inside (A)
Outside (B)
Inches
Inches
Inches
Inches
mm
mm
Pounds
Grams
Fractions
decimals
Fractions
decimals
3/8
.375
9.5
3/4
.750
19.1
0.15
68
1/2
.500
12.7
7/8
.875
22.2
0.22
100
5/8
.625
15.9
1.0
1.00
25.4
0.35
159
3/4
.750
19.1
1-1/4
1.250
31.8
0.58
263
3/4
.750
19.1
1-5/16
1.313
33.4
1.00
454
7/8
.875
22.2
1-1/2
1.50
38.1
1.05
476
15/16
.938
23.8
1-1/2
1.50
38.1
1.10
499
1-1/8
1.125
28.6
1-3/4
1.75
44.5
1.60
726
1-3/16
1.188
30.2
2.00
2.00
51
2.00
907
1-1/4
1.250
31.8
2-1/4
2.25
57.2
3.00
1361
1-3/8
1.375
35.0
2-1/2
2.50
64
3.50
1588
1-1/2
1.500
38.1
2-3/4
2.75
69.9
4.80
2177
1-3/4
1.750
44.5
3.00
3.00
76.2
6.00
2722
2.00
2.00
51
3-1/2
3.50
88.9
10.00
4536
2-3/8
2.375
60.3
4.00
4.00
101.6
15.00
6804
2-5/8
2.625
66.7
5.00
5.00
127
25.00
11340
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for information only.
3. Based on the rope size.
4. Use the thimble size "fractions" for PIN.
FIGURE 1. Type 1, split round fiber rope thimbles - Continued.
3.3.2 Type II. Light thimbles shall be of the split oval construction, semi-circular at the closed ends, with the
sides tapering together at the free ends. The free ends shall have a rounded shape. Light thimbles shall conform
to the design and dimensions shown on figure 2.
See notes at end of figure.
FIGURE 2. Type II, split oval, light fiber and wire-rope thimbles.
