FF-T-276C
Thimble size, see note 3
Circumference
Nominal diameter
Inches
Inches
Inches
Inches
(mm)
mm
fractions decimal
Fractions
decimal
5/16
.312
7.8
3/4 to 1
.75 to 1.0
19.1 to 25.4
3/8
.375
9.5
1-1/8
1.13
28.7
7/16
.438
11.1
1-1/4
1.25
31.8
1/2
.500
12.7
1-1/2
2.50
64
9/16
.563
14.3
1-3/4
1.75
44.5
5/8
.625
15.9
1-7/8
1.88
47.8
11/16
.687
17.4
2
2.0
51
3/4
.750
19.1
2-1/4
2.25
57.2
7/8
.875
22.2
1-1/2 to 2-3/4
1.5 to 2.75
38.1 to 69.9
1.00
1.00
25.4
3
3.0
76.2
1-1/8
1.125
28.6
3-1/4 to 3-1/2
3.25 to 3.5
82.6 to 88.9
1-1/4
1.250
31.8
3-3/4
3.75
95.3
1-3/8
1.378
35.0
4
4.0
102
1-1/2
1.500
38.1
4-1/2
4.5
114.3
1-3/4
1.750
44.5
5 to 5-1/2
5 to 5.5
127 to 139.7
2.00
2.00
51
6
6.0
152.4
See notes at end of figure.
FIGURE 1. Type 1, split round fiber rope thimbles.
4
