AN116 Rev 3
Table I. Dimensions for shackle, anchor, forger carbon steel screw PIN continued. 1/2/3/4/5/6/7/8/9/
AN Part
L
P
or Identifying
Inside
Pin dia.
Number
length
(mm)
(PIN)
(mm)
AN116-3
.875(22.22)
.250(6.35)
+ .016(.41)
- .000(0)
AN116-4
1.125(28.58)
.312(7.92)
± .062(1.6)
AN116-5
1.250(31.75)
.375(9.53)
AN116-6
1.438(36.53)
.438(11.13)
AN116-7
1.688(42.88)
.500(12.7)
AN116-8
1.938(49.23)
.625 (15.88)
AN116-9
2.125(53.98)
± .0125(.318)
AN116-10
2.500(63.5)
.750(19.05)
AN116-12
3.000(76.2)
.875(22.23)
1.000(25.4) + .031(.79)
AN116-14
3.250(82.55)
1.125(28.58) - .000(0)
AN116-16
3.750(95.25)
AN116-18
4.250(107.95)
1.250(31.75)
± .250(.635)
AN116-20
4.500(114.3)
1.375(34.93)
AN116-22
5.250(133.35)
1.500(38.1)
AN116-24
5.750(146.05)
1.625(41.28)
AN116-26
6.250(158.75)
1.750(44.45)
AN116-28
7.000(177.8)
2.000(50.8)
AN116-32
7.750(196.85)
2.250(57.15)
See notes at end of table.
