A-A-55606A
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Anchor, guy, and rods, anchor supplied to this CID shall be as specified
herein.
3.2 Material. The material shall be UNS G10350 steel in accordance with ASTM A29/A29M.
3.3 Finish. Guy anchors and anchor rods shall be hot-dip galvanized in accordance with ASTM A153/A153M.
3.4 Threads. Anchor rod threads shall be as specified in FED-STD-H28/2. Rods for plate anchors shall be
threaded to a minimum of 3.5 inches. Rods with separate eyes shall be threaded to a minimum of 1.5 inches.
3.5 Nut. A nut shall be included with each rod anchors from table 6.
3.5.1 Nut and Bolt. A high strength nut and bolt shall be included with each extension and guy adapter from
Table 7.
3.6 Dimensions. Dimensions shall be as described in tables I, II, III, IV, V, VI, and VII.
TABLE I. Plate anchors.
Part
Hole
Rod
Anchor
Plate
code
size
diameter
Area
Type
1A
6
5/8
70
Expanding
1B
8
5/8, 3/4
135
Plate
1C
10
3/4, 1
200
1D
12
1, 1-1/4
300
1E
16
5/8, 3/4
150
Cross
1F
20
5/8, 3/4, 1
250
Plate
1G
24
5/8, 3/4, 1, 1-1/4
400
TABLE II. Screw anchors, no wrench, triple strand eye.
Helix
Rod
Torque
Rod
Part
Diameter
Diameter
Capacity
Length
Code
2A
4
3/4
400
54
2B
6
3/4
400
66
2C
8
1
1000
66
2D
10
1-1/4
2300
66
2E
10
1-1/4
2300
96
2F
14
1-1/4
2300
96
2
