[INCH-POUND]
A-A-55603A
10 October 2012
SUPERSEDING
A-A-55603
2 May 1995
COMMERCIAL ITEM DESCRIPTION
CLAMP, GUY (POLE LINE)
The General Services Administration has authorized the use of this
commercial item description for all federal agencies.
1. SCOPE. This commercial item description (CID) covers the general requirements for clamp, guy,
(pole line). clamp, guy, (pole line) covered by this CID are intended for commercial/industrial applications.
2.CLASSIFICATION/PART OR IDENTIFICATION NUMBER (PIN). This CID uses a classification system
which is included in the PIN as shown in the following example (see 7.1).
AA55603
-
001
CID number
Dash number
2.1 Dash numbers. See table I for all dash numbers and their associated dimensional information.
3. SALIENT CHARACTERISTICS.
3.1 Interface and physical dimensions. Clamp, guy, (pole line) supplied to this CID shall be as specified
herein (see figure 1) and dimensions in table I.
3.2 Material. The material shall be carbon steel in accordance with ASTM A29/A29M.
3.3 Finish. The finish shall be (hot dipped) in accordance with ASTM A153/A153M.
3.4 Screw threads. All screw threads shall be UNC-2 as specified in FED-STD-H28.
3.5 Galvanized. All screw threads shall not be galvanized.
Comments, suggestions, or questions on this document should be addressed to DLA Land and
Maritime, Attn: VAI, 3990 East Broad Street, Columbus, OH 43218-3990 or fluidflow@.dla.mil.
Since contact information can change, you may want to verify the currency of this address
information using the ASSIST Online at https://assist.dla.mil.
AMSC N/A
FSC 4030
